AMPLIFIER RESEARCH AR 20T4G18, 20W,4.2G-18GHz RF Power Amplifier

POWER (fundamental), CW, @ OUTPUT CONNECTOR

 Nominal:42 watts

 Minimum :20 watts

 Linear @ 1dB Compression: 10 watts minimum

FLATNESS:±9 dB maximum, 4.2 - 18 GHz

 ±5dB maximum, 8.0 - 18 GHz

FREQUENCY RESPONSE:4.2 - 18 GHz instantaneously

INPUT FOR RATED OUTPUT:1.0 milliwatt maximum

INPUT IMPEDANCE.:50 ohms, VSWR 2.0:1 maximum

OUTPUT IMPEDANCE: 50 ohms, VSWR 2.5:1 typical

More datasheet please look at the data file.

Good working ,if having other require please contact .
