The Boonton 4500B 30 MHz to 40 GHz Peak Power Analyzer is the instrument of choice for capturing, displaying, analyzing and characterizing RF power in both the time and statistical domains.



The 4500B power meter has two basic measurement modes - pulse power and modulated power. In pulse power mode, the 4500B functions as an enhanced peak power analyzer with the ability of viewing the RF envelope of signal frequencies up to 40 GHz.



The RF frequency range and detection bandwidth are naturally sensor model dependent.



The Boonton 4500B has a built-in 1 GHz step calibrator which enhances the measurement accuracy by performing an automatic routine calibration to the connected Boonton sensor model.



The calibration process can be performed by connecting a peak power sensor to the calibrator output terminal of the Boonton 4500B peak power meter.



This application note describes various uses and applications of the internal calibrator of the Boonton 4500B power meter











The price include the shipping cost (By DHL or FEDEX).



If having other require ,please contact.
